The robotic stacker is designed to work with plastic cup thermoforming machines, where it automatically picks finished cups directly from the mold and arranges them neatly in stacks for collection or packaging. By integrating robotic precision, the thermoforming system improves efficiency, consistency, and hygiene in the production of plastic cups, reducing manual handling and labor costs.
| Model | Use for plastic cup making machine | |
| Power supply |
|
|
| Arm servo motor | 0.75kW | |
| Lifting servo motor | 1.0kW | |
| Conveyor belt motor | 0.4kW | |
| Self-running speed | ≤ 30 cycles/min | |
| Air pressure | ≤ 0.8MPa | |
| Exhaust volume | Approx. 0.5m³/min | |
| Dimensions (L×W×H) Machine | 1100×1500×1800mm | |
| Dimensions (L×W×H) Belt conveyor | 3000×850×900mm (height adjustable) | |
| Weight | 600kg | |
Partner with us for efficient, precise, and sustainable thermoforming and extrusion machines made to meet global market demands.
Contact us today!
Typically, plastic cups and bowls are manufactured from highly transparent materials such as polypropylene (PP) and polyethylene terephthalate (PET). This demands exceptionally high standards in stretch forming technology, and our thermoforming machines for plastic cups can provide customers with production capabilities.
Yes, ice cream cup is made from PET material, this plastic cup forming machine supports thermoforming processes using polyethylene terephthalate (PET) materials, ensuring compliance with the hygiene standards and transparency requirements necessary for food packaging. It can be used to manufacture ice cream cups in a variety of complex shapes.
